lithium ion 13s8p 18650 48v battery pack bateria ion litio 48v 20ah electric scooter battery 48v 20a

No.

Item

Characteristics

Remarks

 3.1

Nominal Capacity

Minimum:19Ah

Typical:  20Ah

Standard discharge(0.2C₅A)

after Standard charge

3.2

Nominal Voltage

42v

3.3

Charging Cut-off Voltage

54.6V

3.4

Discharge Cut-off Voltage

39V

3.5

Standard charge

Constant Current 0.5C₅A

Constant Voltage 8.4V

0.01 C₅A cut-off

Charge time : Approx 4.0h

3.6

Maximum Constant Charging Current

20A(1.0C)

3.7

Standard discharge

Constant current 0.2 C₅A

end voltage 6.0V

3.8

Maximum Continuous Discharging Current

20A(1.0C)

3.9

Operating Temperature

Charge       0~45u2103

Discharge  –20~60u2103

3.10

Storage Temperature

-20~45u2103 for 1Month

-20~35u2103 for 6Months

3.11

Environmental request

RoHS

If the materials of the product and packaging accord with RoHS standard,there will be a RoHS Id on the box.
