YK-3-1 repair car polisher preparation station

Guangzhou Yoki Machinery Manufacturing Co., Ltd. is an international cooperative enterprise specializes in automobile spraying booth, industrial coating equipments, automobile maintenance equipments. We intend to provide high-quality paint spraying equipments corresponding support equipments, and well technical services to the automobile after-sales fields and industrial machine manufacturing fields of the world by advanced manufacturing technology and design standard

Inside dimension6300u00d73450u00d72800mm(LxWxH)

Outside dimension7550u00d73550u00d73500mm(LxWxH)

Basement & FloorComplete Steel assemble,with 3 rows of indented plate & 2rows of grille

Rampwith 2pcs ramp,each one: 2000u00d7750u00d7300mm(LxWxH), color:blue,

Ceiling SystemDimension:6400X3550X520mm(LxWxH), with lights on 2 sides of roof,part of roof with air-proof plate,other part with filter.

Generator SettingBack exhaust air,with quadrate steel frame, blue coated steel

Intake &Exhaust air systemGenerator dimension: 1300u00d71100u00d71100 mm(Lu00d7Wu00d7H);with 1set 7.5KW fan for intake air, belt-drive motor position: outside; Air capacity:21000M3/H.Electric damper control the air capacity of intake and exhaust system

With 1 set 5.5KW fan for intake air, belt-drive motor position: outwide; Air capacity:18000 M3/H.

Seal Type3 sides set with 50mm EPS heat preservation panel, with 8 pcs sight glass on the panel; PVC curtain color: upper part: white, middle part:transparent lower part: blue

Filtering SystemPre-filter pocket, Ceiling filter, Floor filter(fibreglass).

Lighting System8units x 4pcs=32pcs36W

Control SystemControl the operation of fan, lighting and electric damper.

Voltage frequencyAs request

Total Power8.7KW

YK-3-1
