hager mw miniature circuit breaker

hager model miniature circuit breaker, mw mc mt type mcb, best price, quality warranty.

a)The terminal connecter is muiti-function if tighten the screw ,upside can connect with copper connector,underside can connect with round wire seperately.And also can combine with the copper connect(flat)and round wire at the same time for both sides.It has the visible contact block breaking indicate equipment ,can be used in wire isulating Full-Scale:A)The operation chaacteristic can be made as B.C and D style, it can meet differet demands.

b) Combined with earth leakage protect equipment ,can be used as earth leakage circuit breaker.

c)Combined with isolated tripping in stroment or voltage shortage tripping instroment,it can realize far distance control and voltage shortage prtection.

d) Combined with contact block or warning instroment and other accessories ,will be used in the porer supply systems of morden intelligent architrcture.

Poles(P) 1,2,3,4

Case grade rated current lnm(A)

63

Power factor0.4-0.5~0.65-0.7

Electric life (time)25000

Rated curret(A)1,2,3,4,6,10,16,20,25,32,40,50,63

Rated voltage(V)230/400

Rated breaking capacity(A)1000

hager series Mini Circuit Breaker is the new product developed by our factroy.The breaking capacity can pass 10KA,it is used in the circuit of distribution systems for building and similar uses,for untrained use ,no need maintained.This series products applied he latest scientific research achievement and the newly contrivance thinking ,has many patent echnic.This product coforms to IEC60898 nd GB 10963-1999 standards.
