Industrial Round Connector IC300 1000V

Industrial Round Connector IC300 1000V

Specifications

Place of origin: China

Type: Adapter/connector

Brand: Anen

Model Number: IC600

Color: Red/Green/Yellow/Blue/Black

Rated Voltage: 1000V

Rated Current: 300/600/1000A

Contact Material: Silver Plated Copper

Size Wire:50-240mm²

Flammability: UL94V-0

Name: Anen Industrial Round Connector

Packaging & Delivery

Packaging Details:

8 set/carton

Delivery Detail:

Shipped in 7 days after payment

Product Description

Anen IC Series connectors are specially formed, resilient strips of copper alloy which are silver or gold-plated according to their application and are float mounted in a groove. By its constant spring pressure the connector maintains continuous contact with the contact surface, resulting in a low and constant contact resistance.

This technology of the connector allows us to meet a very broad range of requirements and to find solutions to the most severe constraints, including electrical (up to several ka), thermal (up to 350 u2103) and mechanical, with contact durability of up to 1 million mating cycles.

we are specialized in the design of custom solutions.

Advantages of Anen industrial round connector

·Minimal voltage drop

·High current-carry capacity

·Minimal power loss

·Minimal contact resistance

·High durability contacts withstand up to 1 million mating cycles

·Operating temperatures up to 350°, higher temperatures permitted for short periods

·High resistance to vibration, shock and impact

·Low maintenance costs

·Round, flat or spherical types

·Very good corrosion resistance

Product Use

Used in standby power units, test stands, switchgears, construction machinery as well as on- and off- shore applications with harsh environmental conditions.

Application with standby power supply unit, generating set, test equipment, complete equipment, mobile power supply vehicle, UPS power supply vehicle, power battery charging and electric vehicle charging pile .
