Zinc Alloy 90 Degree Elbow Flexible Conduit Connector

Product Description

Elbow Liquid Tight Flexible Conduit Connector
1.Thread type:NPT3/8" to NPT2"
2.Applicable conduit:3/8"-2"
3.Material: Zinc Allloy

Product Feature

Product Features of Elbow Liquid Tight Flexible Conduit Connector
1.Patented split gland-ring is designed to slip into the conduit quickly and go grip the jacket of the conduit, speeding installation, assuring a perfect seal, and preventing pullouts.
2.All components are reused. KT-FLEX liquid tight connector can be easily disassembled and reused after years of service.
3.Sealing washer (included) provides a liquid tight seal when terminating the connector in a threadless opening.
4.Heavy duty locknut included with every KT-FLEX liquid tight connector assures continuity of ground.
5.All metallic components are electro plated for adding corrosion protection.
6.Bodies- 3/16" to 4" iron, stainless steel or brass; Locknuts-3/16" to 4" iron, stainless steel or brass.

Product Specification / Models

Elbow Liquid Tight Flexible Conduit Connector
1.Thread type:NPT3/8" to NPT2"
2.Applicable conduit:3/8"-2"
3.Material: Zinc Al

Application / Models

Application of Elbow Liquid Tight Flexible Conduit Connector
1.For use in outdoor or indoor locations on flexible metallic conduit or liquid tight conduit in Power plant, Power transmission system, communication system, building factory, railway, train, transportation system project, air conditioner, various machines, automates controlling plant. And protecting the electrical wire or cable outside the construction and plant.
2.Use to positively bond the conduit to a box or enclosure.

Other Information

Products & Service
* Squarelocked & Interlocked galvanized flexible conduit
* Squarelocked & Interlocked stainless steel conduit
* PVC coated steel conduit
* Liquid tight flexible conduit
* Heavy duty waterproof conduit
* Stainless steel braided conduit & cable sleeve
* Explosion proof flexible conduit
* Non-metallic liquid tight conduit (polyamide, polythene, polypropylene)
* Split nylon corrugated conduit
* Liquid tight flexible conduit connector
* 45 degree & 90 degree conduit box connector
* EMT conduit union & Conduit to pipe coupling
* Brass & nylon cable gland
* Conduit pipe clamp
* Conduit pipe reducer & extension
* EMT conduit bushing & locknut
* Electrical conduit ferrules
* OEM is welcome
About kt-flex:
KT-FLEX Co., Ltd is registered in Tianjin Binhai New Area, is a high technology enterprise which is specialized in manufacturing high quality flexible conduit, connector and complementary fittings. Our company owns a high-level R&D, production,sales and service working team. In order to ensure quality, the company constantly increases the investment on manufacturing equipment, now it has the international advanced production equipment and testing equipment, improved the quality testing and control systems, got the ISO 9001:2008, Explosion proof certificates. Bearing the belief of "quality is life, service is future", adhering to "persist producing independent intellectual property right products as core", have created "KT-FLEX" brand.
