USTC WIRE

HAVERER GROUP proud to produce all kinds of wire.html'>USTC Wire in China. What is wire.html'>USTC wire? It is insulation wire covered with one layer or multi layer insulating fiber (nylon, polyester fiber, natural silk and adhesive silk) on the surface of single enameled wire or stranded wire.
USTC wire is a special type of wire used in electronics. The wire is designed to reduce the skin effect and proximity effect losses in conductors. It consists of many thin wires, individually coated with an insulating film and twisted or woven together, following a carefully prescribed pattern often involving several levels (groups of twisted wires are twisted together, etc.).

ustc wire,litz strands,strand wire,Braided Wire,Copper Wire

The benefits of using litz are:
1. Increased efficiency
2. Mitigation of skin and proximity effect
3. Minimum eddy current losses
4. Lowered operating temperatures
5. Reduced footprint of final product
6. Substantial weight reduction
7. Avoidance of "hot spots"
Typical applications for USTC wire conductors include high-frequency inductors and transformers, motors, relays, inverters, power supplies, DC/DC converters, communications equipment, ultra-sonic equipment, sonar equipment, television equipment, and heat induction equipment.



Specs:
Single enameled wire: 0.016mm-1.00mm,
Number of strands: 2-10000
Coating, with one layer or multi layer insulating fiber (nylon, polyester fiber, natural silk and adhesive silk) on the surface of single enameled wire or stranded wire.

ustc wire,litz strands,strand wire,Braided Wire,Copper Wire
