Rg8 Coaxial Cable

Rg8 Coaxial Cable

1)2.77mmBare Copper+7.25mmFoamed PE+A/P/A(bonded)+95% Tinned Copper Braiding+10.30mmPVC

2) Customers' specifications are welcomed



Note:

1) Center conductor: Tinned Copper, Bare Copper, and Copper Clad Steel available;

2) Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil,

And double non-bonded Al-foil are available;

3) Braiding wire: AL, Bare Copper and Tinned Copper available;

4) Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;

5) Braiding net: 80, 96, 120, 128, 144 and more available;

6) Braiding coverage: Between 80- 97% available;

7) PVC jacket of Flame retardant, UV, or UL available.

Characteristics:

Impedance: 50+/-2 Ohm

Velocity of Propagation: 85%

Capacitance: 24.8pF/ft



Attenuation:

[@68 F. (20 C) ] dB/100feet [@68 F. (20 C) ] dB/100feet

5MHz: 0.4dB 900MHz: 4.1dB

10MHz: 0.5dB 1000MHz: 4.4dB

50MHz: 1.0dB 1500MHz: 5.5dB

100MHz: 1.4dB 1800MHz: 6.1dB

200MHz: 1.8dB 2000MHz: 6.5dB

400MHz: 2.6dB 2500MHz: 7.5dB

700MHz: 3.6dB 3000MHz: 8.3dB.
