S(D)XXSXX-XW (1W Max)

Characteristic

Mark

Term

Unless otherwise specified

Vi ,-25℃≤Tc≤85℃

Limit value

Unit

Min

Max

Output voltage

Vo

full-load

Vo-2%

Vo+2%

V

Max output current

Io

-

-

Po/Vo

A

Output ripple voltage

Vp-p

Full-load, Vi，BW=20MHz, common temperature

-

50

mV

Load regulation

Si

Vi，Io=(50%~100%)Iomax

-

1.00

%

Efficiency

η

Vi，full-load，common temperature

75．00

-

%

Voltage regulation factor

RI

Plus 1000VDC between input voltage and output ground, common temperature, t≥3S

50

-

MΩ

General characteristics

electromagnetic compatibility

GB9254-2008

GB17625.1-2001

EN55022-2006

EN55024/A1-2001

temperature drift

0.02%/℃

frequency

100K～220K HZ

humidity

95% (max)

leakage current

0

MTBF

>2,000,000 hours

Product features

constant input voltage

full-load efficiency

work temperature: industrial grade -

1000VDC isolation voltage 0.5mA 1Minute

apply Surface Mount Technology

international standard pin

high inflaming shell package

pass ROHS Complaint

■cooling method: natural cooling

good functions of anti-interference, electromagnetic compatibility, Output over-current protection, short-circuit protection, over-temperature protection, self-resumption

S(D)XXSXX-XW (1W Max)

Industrial control and DC system, switching system, A/D and D/A, railway, NCIT, cell phone, semiconductor laser, display screens, monitoring -equipment, petrochemical industry, portable instrument, medical instrument, self-control device, anti-theft alarm, handle instrument, digital circuit, IC card electric meter, AC AC control unit, etc.
