DME standard plastic injection mold

We are a professional manufacturer specializing in the design and manufacturing for plastic injection molds and plastic injection

We have an experience of 18 years in this field

We mainly develop the market of automotive parts, home appliances, electronic products/industrial components and more

We has a strong technical force with a team of experienced designed engineers and mold makers, also fully equipped with advanced facilities

Products quality is the lifespan of an enterprise

Is the company's tenet, so we are striving to achieve the goal of zero defect

Always with the operating philosophy of quality first, efficiency precedes and customer orientation

We provide our customers' with first class level quality molds through insistent efforts, pursuit of perfection and continuing innovations

We also provide assembling service of the injected products if required

And we provide one bucket service of printing and surface coating, all done in our own factory

Our team consists of professional technical people that can communicate with the customers' without obstacles

Sincerely we hope that we can provide every distinguished customers' with the best, in time and the most professional services, helping you to save both time and cost at maximum

1.Plastic Injection Mold standard: HASCO,DME,MEUSBURGER,JIS,CHINA LKM STANDARD

2.Mold base: LKM&Hasco&DME standard (A,B plate 1730,2311,2312,P20 )

3.Material main core and cavity insert: DIN2312,2738,2344,718,S136,8407,NAK80,SKD61,H13

4.Hardness of steel: 46~56HRC

5.Material for Slider, Lifter and all sub insert use:1.2767

6.Cavity: Single-cavity, Multi-cavity

7.A surface request: EDM & High Polish

8.Gate: Yudo/DME/HASCO/Synventive Hot runner,Cold runner

9.Maximum mold size: 1500*1500 mm

10.Mold life time: 500000~+1,000,000 shots

11.Quality: ISO9001-2008 certification

12.Product material: PA,PA6/6+GF,ABS,POM,PC,PP,PET,TPE,PVC,HDPE etc

13.Value-added service: Polish,texture,painting,screen printing,turnkey project

14.Lead time: 4~7 Weeks

15.Package: Wooden/Plywood case for tool ,PE bags add export carton for parts

16.Payment terms: T/T

17.Trade terms: FOB Xiamen

Automobile :Air outlet / vent, Rearview mirror, Instrument panel, Horn, seat

Electronic : Wireless receiver part, 3G/4G Modem Wireless Network Cards,USB housing, Mobile phone plastic part, remote control , key-press

Mechanical :Junction box, Motor support part , Pump plastic part,mower

Household :Industrial number calculator part,Juice cup,safety helmet

Medical :hearing aids, Hollow fiber Dialyzer, Blood-Pressure meter, Stapler

Sport :Golf plastic part

Office: Secret code case part, Printer, duplicator, Atom seal
