ZSC-3 motor oil recycling machine to good base oil

Product Description

oilpurifier_sunnyAThotmail.com

Through many years' hard work, the Company successfully developed the ZSC series engine oil purification and discolourization purifier, which is a breakthrough in oil depolarization--a worldwide difficulty. This purifier can remove the tiny impurity dispersed in oil such as carbon particles and deep oxides, as well as bad substance such as colloid and asphalting. Thus, the clarity of oil recovered, engine oil quality is improved, performance of engine is restored, abrasion reduced. These would ensure correct operation of lubricant system of an engine and extend the life time of engine oil and engine as well. This kind of purifier is applicable to purification of various engine oil used for transport facilities such as ship and automobile.

Product Feature

( 1)It is a physiochemical application to eliminate the electric charge between polar particulate in waste oil, which is gathered into large particles and separated. The colloid, asphalting and other compound in oil are also removed while harmful gas and the water content are removed by the waste gas cleaner and the vacuum degas function. Thus, the oil is cleaned and the effective constituent of oil is retained.
( 2)High precision stainless steel net is used, which is anti-corrosive, high temperature resistant and has a good mechanical strength and long lifetime. It is easy to use, and utilizes the economical pressure filter as filter medium.
( 3)Novel structure, good layout and is deemed as a "Mini Refinery".
( 4)Very straight and evident effect and the machine can be used for multiple purposes.
( 5)Can be tailored to meet the needs of an individual customer.

Product Specification / Models

Name Unit ZSC-1 ZSC-2 ZSC-3 ZSC-5 ZSC-8 ZSC-10 ZSC-15 ZSC-20
Handling Capacity Ton/day 1 2 3 5 8 10 15 20
Recovery rate % 87~92%
Color Grade 2~3
Flash Point u2103 ≥220(according to the oil)
Acid Value mgKOH/g ≤0.1
filter precision μm ≤5
moisture content ppm National standard(trace)
working noise db(A) ≤70
oil pump pressure Mpa ≤0.4
power supply 380V 50HZ(can be adjusted as the requirement of users)
Heating power KW 48 60 72 96 144 168 225 340
Total Power KW 65 75 90 115 165 185 245 368
Heating time Hour 2 2 2 2 2 2 2 2
Filtering surface area m2 6 10 15 20 25 30 50 60
Mixing speed times/min 13 13 13 13 13 13 13 13
Total Weight KG 2600 3000 3500 4500 5500 7200 9200 11600
Technical Parameters of ZSC series
Dimension and weight will be changed with changing the technical specification.

Application / Models

black engine oil filter,black oil regeneration,motor oil filter,motor oil recycling machine
