Abrasion resistant UHMWPE polyethylene plastic drag conveyor paddle

Abrasion resistant UHMWPE polyethylene plastic drag conveyor paddle



UHMW-PE parts:

UHMWPE material has many advantage to make it to be the ideal material as different Industry elements and equipments. Owing to its excellent abrasion resistance, impact resistance, self-lubricating, it is suitable for making many types of machinery parts, such as rollers, shaft bushes, nozzles, mixing blade and other products.



XINXING CNC machined UHMWPE parts:Our CNC machine can make drillings, do chamfers, and do other processing under the control of computer.Our professional workers can process the UHMWPE sheet and rod into different shape as customer special request. If you have special parts troubled you, please feel free to contact us. Your approval is our greatest satisfaction!



Our Company Introduction:

Shandong Ningjin Xinxing Chemical Co.,Ltd. is the leading professional Engineering Plastic products manufacture in China which specialized in producing UHMWPE and HDPE products according to the requirement from customers. XINXING has been specializing in this area since 1995, and the products are selling in more than 30 countries and area, such as North America, Europe and Southeast Asia and so on.



In the recent years,XINXING become the one of the largest UHMWPE Products manufacture in the world.



Our Products Range:

UHMWPE Sheet,UHMWPE rod,UHMW-PE liner,UHMW-PE Strips,UHMWPE Filter Plate,UHMWPE Marine fender pad, UHMW-PE parts, UHMWPE pad, HDPE Sheet, HDPE bar, HDPE parts, PP Sheet, PVC sheet and other Engineering plastic products.

.

Our Products Type :

PE 300,PE 500 ,PE 1000,PE 2000

UHMWPE 3million----9million molecule weight

High Density Polyethylene

Different shape and size is also available



Our Sheet Standard Sizes:

Length(mm)Width(mm)Thickness(mm)

200010006-300

300015006-300

470012006-300

500013006-300

450020006-300

305012206-100

Any small size need us to cut , we can satisfy your special need .



Our Products Color:

Black,Blue,Green,White,Yellow,Red,Orange or other customer color according to your requirements



Our Machine Character:



Our company adopted the most advanced Oriented type pressing machine,the pressure can be up to 1500t/M2, The pressure is ten times of normal pressing machine.The most important is that we have guide post which make the pressing machine rise steadily and the sheet can be strengthened evenly and smoothly.

This processing method is called pressure molding means .Its main character is it will not affected by the molecule weight of UHMWPE.Even the highest molecule weight of UHMWPE can be reprocessed by our machine.

UHMWPE Advantages & Key Features:

Ultra High Molecular Weight (UHMW) Polyethylene is often referred to as the world toughest polymer, which is an optimum material instead of rubber, metal and wood. It is lighter and has lower coefficient of friction than rubber. UHMW-PE products are easier to be fixed and maintained so as to reduce the cost, and especially resistant to the corrosion of water in the sea and ocean.

The following character also make the UHMW-PE products become most popular in the world.

--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel

--Anti-Weather & Anti-Aging

--Self-lubricating, Very low coefficient of friction

--Excellent chemical & corrosion resistant

--superior impact resistant, Noise- absorption, Vibration-absorption

--Temperature range: -260u00b0C~ +80u00b0C; Very high resistance to cold,doesn't become fragile even under -180u00b0C

--High tensile Strength

--Non-Toxic and smell

--UV resistance

--Flame Retardant; Relatively low in water absorption

--Excellent electrical properties

--Good performance in resisting environment stress crack, 200 times of ordinary PE

--No adhesion

--Light weight and easier to handle and fix

--Cost efficient; Resulting in low energy consumption

--Does not rot, split or crack; 100% recyclable

--Great liner material for industrial material handling applications

--Easy Reprocessed

Specification:

Place of Origin:Shandong China (Mainland)

Brand Name:XINXING

Material : UHMWPE

Thickness : 6-300MM

Size : as you required

Standard color ; white/natural/blue/green/black/yellow/red/orange(other color is available )

Inspection : GB/T 19001-2008 ; ISO 9001:2008

Molecular weight : 3million -9million

Breaking elongation: >300%

Thickness tolerance : +2 -1 (smaller made according to your requirements)

shape : sheet/board/pad/panel/roll

Density : 0.93-0.97

Ultimate strength : 45MPa

Friction Coefficient : 0.12-0.15

Impact strength : 131Mj/mm2

Abrasion : 80, steel = 100

Application:

--Transportation machinery: Guide rail, convey belt, convey device slide block seat, fixing board, product flow line timing star wheel.

--Food processing machinery: With its performance of high wear resistance, anti-impact resistance, inadhesion resistance, non-toxic and clean property, UHMWPE material can be used in planet wheel, bottle convey counting bolt, filler bearing, bottle holder parts, washer guide bolts, air cylinder, gear, roller cone, chain wheel handle, which is easy-cleaning, long-enduring, and anti-mildew.

--Paper making machinery: With its performance of high wear resistance and good self-lubrication, UHMWPE material can be used in water suction tank cover, skew guide wheels,scrapper , bearing, nozzle, filter, oil tank, friction bar, felt cleaner.

--Textile machinery: With its performance of high-wear resistance, anti-impact and good self-lubrication, UHMWPE material can be used in scutcher, shock absorber shield, contactor, crankshaft connecting rod, picker stick, skew rod shaft sleeve, swing rear beam.

--Construction machinery/agriculture machinery: Bulldozer blade lining. Dumper ripper lining, tractor plow inner lining.

--Chemical machinery: Valve, pump, washer, filter, gear, nuts, seal rings, nozzle, plug, shaft sleeve, thread pipe.

--Port machinery/ship machinery: Ship parts, suspension bridge side roller, friction block.

Ordinary machinery: All types of gear, bushing, liner, sliding plate, clutch, guiding unit, brake, hinge, flexible coupler, roller, bearing wheel, fastening unit, platform sliding unit.

--Dyeing decor: Dip dyeing machine bearing, scrapper, sliding plate, lining washer, seal, framing guide disc,

--Culture and sport products: Snow dip liner, powered sledge, skating rink paver, ice field protection frame.

--Healthcare products: Shape righting surgery, artificial joint, artificial limb.

--Other: Cooling machine, nuclear power plant shield, electric galvanized parts, and ultra-low temperature machine parts.Mostly using of its high-wear resistance, high anti-impact resistance, anti-cold resistance, self-lubrication.

Why Choose Us:

20 years' professional manufacturing experience with own factory.

Virgin 100% material produced, recycle material available, high quality with good surface and color make ensured

GB/T 19001-2008 ; ISO 9001:2008 certification.

Competitive price, In stock, Fast delivery, and Excellent service.

OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.



Any questions, please feel free to contact us.
