FIBER LASER MACHINING SYSTEM WITH CNC ROSTEHNO LAZER L-1000

The fiber laser Rostehno lazer L-1000 is a heavy-duty equipment with high accuracy for working with metals. The machine is meant for cutting metallic materials, such as stainless and carbon steel.

The modern fiber laser machining system Rostehno lazer L-1000 is a high-accuracy and high-speed equipment for cutting metals (stainless and carbon steel).

Model: Rostehno lazer L-1000

Manufacturer: Rostehno

Country of origin: Russia

Type of laser emitter: Ytterbium fiber laser

Manufacturer of laser emitter: Raycus (China)

Power of laser emitter, W: 1000

The resource of the laser emitter, h: 100000

Optical head model: Shenzhen Worthing (China)

Cooling Type: Water

Chiller: CW-6000

Working surface: Knife-like table

Servo motor: Yasukawa (Japan)

Transmission method: Single-sided ball screw

Guide: HIWIN (Taiwan)

Electrical elements: Schneider (France)

Pneumatic elements: Camozzi (Italy)

Control system: Cypcut

Supported formats: DXF, PLT, AI

Positioning accuracy, mm: ± 0.02

Maximum cutting speed, mm / sec: 200

Smoke removal system: Fan

Size of the machine, mm: 3600 * 1900 * 1900

Size of the working surface, mm: 3000 * 1500

The maximum thickness of the cut, mm: 16

Net weight, kg: 2700

Warranty: 2 years
