GFQ-S Automatic sewing machine for woven bag

Model Number GFQ-S

Type Packing Machine

Condition New

Application Food, Commodity, Medical, Chemical

Packaging Type woven bag

Automatic Grade Automatic

Driven Type Pneumatic

Voltage 380V

Power 820W

Place of Origin Anhui, China (Mainland)

Brand Name Yuanhong

Weight 430KG

Dimension(L*W*H) 1230*890*1240MM

Certification ISO

After-sales Service Provided Overseas service center available



Technical parameters:

1. Bag Size(unit: mm):(650~1000)u00d7(350~550)(Lu00d7W)

2. Max packing speed: 25 packs/min

3. Sewing Machine Head: NP-7A-type (Japan NEWLONG)

4. Finished conveyors: chain plate conveyor (L = 2.5m)

5. Total power: 820W 380Vu00b110% 50HZ

6. Air pressure :0.5~0.7Mpa

1. Using photoelectric sensor switch automatically locate Sewing

2. Automatically disconnected, no artificial tangent

3. Sewing-oriented and product conveyor drive motor equipped with the drive, adjustable speed

4. Finished conveyor can be adjusted up and down the table to meet the needs of the different length of the bag

5. Sewing machine head is equipped with safety switch safety cover, remove the safety cover off automatically after the sewing machine head, good safety performance

6. The frame is board connecting structure, elegant appearance packing machine)
