high speed Nasal filling and capping machine production

1.includes bottle unscrambler , high speed spray filling and capping machine

2.Production capacity:40-80 bots/min

Contact information:

Skype:amandachow88

Email:shnfmachinery@gmail.com

Tel:0086-18622303953

The line includes bottle unscrambler , high speed spray filling and capping machine

The bottle unscrambler is round bucket unscrambler. Poured the disorderly bottle into the bucket . When bottles are transported out, they are in order and the mouth is upwards. Then they will goes to the transition turntable which has double track. Through the turntable the bottles enter to the filling and capping parts. The machine adopts linear filling. After filling it will finish adding nozzle and capping in turntable. There are two choices:component positioned capping or vacuum suction the nozzle and adding it. Then it finish correction and capping task. The line is used for medical, chemical and food industries.

Main technical parameters of high speed spray filling production line

NO.NameSpecification

1Production capacity 60-80 bots/min

2Filling error1%

3Filling pumppiston pump (glass pump, peristaltic pump)

4Plugging cover rate98%

5Capping headdouble heads

6Capping rate98%

7Voltage220v /50HZ

8Power4 kw

9 Weight650kg

10Dimension2500*1450*1650mm
