GFCK-10 Automatic Granule Bag Given Packing Machine

Basic info:

Model Number: GFCK10

Condition: New

Application: Food, Medical, Chemical

Packaging Type: Bags, Pouch, bag

Packaging Material: Plastic, paper,plastic,woven

Automatic Grade: Automatic

Driven Type: Pneumatic

Voltage: 380V

Power: 5.5kw

Place of Origin: Anhui, China (Mainland)

Dimension(L*W*H): 3450*2430*3560MM

Weight: 1560KG

Certification: ISO

After-sales Service Provided: Overseas service center available

size: 4500*2200*2100mm

Function: Filling, Sealing, weighing





Technical parameters:

Packaging materials: 1. Woven Bags (covered film)

2. Kraft paper bags

3. Plastic composite film

Package Dimensions (Unit: mm): (500-700) u00d7 (300-400) L u00d7 W

Package weight: 5-10 kg / bag

Measurement accuracy: u00b110g

Speed: 5-8 packs / minute (depending on packaging materials, bags and other dimensions may vary slightly)

Air supply: about 0.5 ~ 0.7Mpa

Power: about 3.2 KW 380 u00b1 10% 50HZ

Dimensions (unit: mm): 3800 u00d7 1800 u00d7 1700 (L u00d7 W u00d7 H)

Seal: 1. Woven bag:lura folding/ seaming

2. kraft paper bags: sealing / seaming

3. composite film bag: sealing

This granule packing machine is developed for powdery material packing in allusion to chemical,feed,grain and seeds field etc. . The unit is provided with the functions of automaticbag-fetching,automatic filling ,automatic bag-conveying nad sealing. Can be linked with all kinds of powder materials production equipment to work to achieve unattended production of large-sized packaging operations. LCD touch screen control.human-computer interface more favorable, automatic fault diagnosis, safety shutdown protection, quick adjustment and easy maintenance.

Food, Medical, Chemical
