Polyurethane Boxing Glove Bladder Foaming Machine

1, Usage

It is widely used in all kinds of hard foam, soft foam, semi-hard foam, wood-like PU products, such as refrigerator, freezer, wood like line, car seat, and steering wheel and so on.



2,feature

1)it is widely used in various materials proportion, which can be adjusted in accordance with real condition.

2)It adopts PLC control program and equips with advanced touch screen. The perfect human-computer interaction makes operation easily and showing clearly.

3)The high accuracy metering pump makes the proportion and output reach to a high level.



3, specification

Hard foam:

Output (g/s): 10-35; 16-66; 66-200; 100-400; 200-600; 350-1000; 900-1800

Power(kw): 9/11/12/30

Range of proportion: 100:50-150

Dimension: with arm 4100Lu00d71250Wu00d72300H(mm)

Weight(kg): 1000/1200/1350



Soft foam:

Output (g/s): 2-6; 6-16; 10-30; 30-80; 50-150; 100-300; 150-400; 200-600

Power(kw): 8/9/11/12

Range of proportion: 100:28~48

Dimension: With arm 1500Lu00d7750Wu00d71500H(mm); With arm 4100Lu00d71250Wu00d72300H(mm)

Weight(kg): 1000/1200
