Main Features:
1.With heating thermostat and testing, large heated area, so that the mold is heated evenly.
2.The use of special processing and assembly process to ensure no easy road with aluminum foil running balance chattering, prompting the graphic on the version is more accurate and stable.
3.PVC bearing material components using large diameter PVC, the whole universal rails, additional equipment machine's usefulness.
4.All material contact parts are made of stainless steel and high-quality materials crafted, high-grade surface treatment, texture prominent.
5.With automatic winding mechanism waste, scrap collecting uniform, finished orderly output, the output port has been installed and the transport mechanism can provide the necessary conditions for the subsequent equipment and production.
6.The machine uses split connector design, easy to transport and into the elevator and workshop.
Main Technical Parameters:
Model | DPB-260 |
Cutting Frequency | Al/plastic:25-60times/min; Al/Al:20-30times/min |
Production Capacity | Al/plastic: 140thousand Grains/hour; Al/Al:7.5thousand Grains/hour |
Max Forming Depth | Al/plastic: 22mm ; Al/Al:18mm |
Travel Range | 30-120mm made to order 140mm |
Total Power | 380V 50HZ 8.5KW |
PVC Rigid Sheet | 0.25-0.5*260 mm |
Dialysis Paper | 50-100g*260 mm |
PTP Aluminum Foil | 0.02-0.035*260 mm |
Cooling | Condensate(self) or cold circulating water(optional) |
Overall Dimensions | 3500*760*1620 mm |
Weight | 1650kg |
