Hot Runner Progressive Mould , Multi - Cavity Injection Molding Tool

Hot Runner Progressive Mould , Multi - Cavity Injection Molding Tool





Quick Detail:



1. The part name: Printer accessories (plastic injection mold)

2. Plastic material: ABS+PC

3. Cavity material: H13 HRC48-52

4. Mold life: 1000k shots or according to customers quantity condition to decide it with saving cost for our customers.

5. Gate type: Point gate, Sub-gate, direct gate, fan gate, edge gate, valve gate, tip gate etc according to our customers requires.

6. Mold base standard: LKM Local standard, DME or HASCO,Customize according to customers' requirements

7. Standard of mold accessories: LKM, DME, HASCO, MISUMI, Meusburger, CUMSA, Progressive, INCORE, HRS, Husky, YUDO, PETS, MOLD-MASTER, MERKLE, Parker, HPS, LKM, EUCHNER, RJG, cilpres, NITTO, CRACK, ASSAB, GSW DIN standard, BOHLER, AISI standard, DAIDO JIS standard, PUNCH etc according to our customers requires.

This product is made of ABS+PC plastic material and it is one of the components of the reputable brand Printer. The mold construction is complicated and there are many inserts, sliders and very thin steel, so it has a very high technical requirement for the mould design. The mould is a hot runner mould with the best water cooling system and the part can be molded by automatically.



This part has very high size requirements, the defect showed below will not be acceptable, for example, weld line, Dark Sport,Sliver Marks,Gas Trap Effect,Visible Ejector Marks,Deformation,Short shot Filling,Burnt Streaks,Sink Marks,Flash,Over dimension,Under dimension,Stress Crack etc. Moreover, the product finishing surface must meet the requires more than SPI-SPE-B2.



This mould is made in Shiny Mould Factory. It is a mould exported to Europe, with complicated structures and high quality requests. Customer needs mold life to be over 1 million shots. We can ensure this mold life and give warrant to our customer that once some mould components are broken during working, if it is caused not by the operation fault from the workers, we can provide new mould components to them free of charge.

Specifications:



1.name

Printer accessories (plastic injection mold)

Plastic material

ABS+PC,GPPS,PP,PE,PA,PC,PC+ABS,POM,PVC,PMMA,PS,PPO,ASA,TPU,

TPR,EVA,PP+GF,PC+GF,POM+GF,PA+GF,PPT,PET,PETG,SEBS etc.

3.mould base material

S50C,P20,S136 etc

4.cavity material

H13 HRC48-52,S136,420, P20, D2, 1040, 0-1, S-7, A2, 1.2344, 1.2083, 1.2311, 1.2739, 1.2343, 1.2510, 1.2767,NAK80,SKD61,718,738,DF-2 etc

5.mold life

1000k shots or according to customers quantity condition to decide it with saving cost for our customers.

6.cavity number

4

7.runner

Hot runner

8.gate type

Point gate, Sub-gate, direct gate, fan gate, edge gate, valve gate, tip gate etc according to our customers requires.

9.mould weight

250 kg

10. mould base standard

LKM Local standard, DME,HASCO,Customize according to customers' requirements

11.cycle time

25second

12. standard of mold accessories

LKM, DME, HASCO, MISUMI, Meusburger, CUMSA, Progressive, INCORE, HRS, Husky, YUDO, PETS, MOLD-MASTER, MERKLE, Parker, HPS, LKM, EUCHNER, RJG, cilpres, NITTO, CRACK, ASSAB, GSW DIN standard, BOHLER, AISI standard, DAIDO JIS standard, PUNCH etc according to our customers requires.

13.design software

Auto CAD ,UG, Pro-E ,Solid Works,Moldflow,etc.

14. File Formats

Auto CAD (DWG), DXF, JPG or JEPG, PDF, Pro-E or Pro/Engineer(DRW,PRT), IGES, STEP,XTL,UG parts etc.

15. injection molding machine

About 120T

16. MOQ

1 set

17. payment

T/T, To be negotiated

18.package

Wooden case or Wooden box with steel frame

19. delivery time(day)

35 T1 according to customers' requirements

20. OEM or ODM

is available

21. mould logo

Based on customer requires

22. after-sales service

one year is warranties

Molding the plastic product by plastic injection machine
