Product Description
Expanded Graphite Sheet
It is Selected from the high purity natural flake graphite.They are made through the advanced chemical treatment and mechanical procedure without fibers, binders or other additives.It offer excellent sealing capabilities under extreme conditions with a longer life and less maintenance.Nuclear Style grade:S586N
Product Feature
Shape (For Gasket): Sheet
Style: Gasket Sheet
Material: Graphite
Function: Packing Rings and Various Kinds of Gaskets
Standard Or Nonstandard: Standard
Product Specification / Models
Temperature:-240~500u00b0C under oxidizing environment
-240~3500u00b0C under non-oxidizing environment
pH Range:0 - 14
Item Nuclear grade Industrial grade
Tolerance of Density g/cm 3 u00b1 0.05 u00b1 0.06
Carbon Content ≥ % 99.5 98/99
Tensile strength ≥ Mpa 5 4
Compressibility ≥ % 30 30
Recovery ≥ % 15 15
Sulphur Content ≤ % 700 1200
Chlorine Content ≤ % 25 50
Stress relaxation rate % 10 10
Lgnition loss ≤ % 0.5 2
DIMENSIONS:
Item Sheets Rolls
Density g/cm 3 1 1
Length 1000, 1500mm 30~100m
Width mm 5~1000, 1500 3~1000~1500
Thickness mm 0.5~3 0.2~1.1
Application / Models
APPLICATION:
Made for packing rings and various kinds of gaskets.
Cut into strip for filler of spiral wound gasket
Used widely in chemical, automotive and pump, valve industries.As a superior replacement for asbestos, new more applications are Being identified daily.
Other Information
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
