Function
Unwinder - Printing(1~4 colors) - Lamination - Die cutter - (Gold Stamp) - Waste Recycle - Paper sheet cutter (or Rewinder)
Advantages
1. Fully automatic control system: auto paper feeding, auto shutdown when without paper or when reaching the preset number of paper.
2. Second printing, multiple printing, backside printing can be achieved.
3. High-speed operation but still accurate in positioning.
4. Advanced ink distribution ensures more even coloring.
5. Inching contact is employed for printing and die cutting during mechanical action, as a result, the pressure is evenly distributed, and clear and spotless printing results can be realized whether for large-sized color base or fine characters.
6. Die cutting unit can be adjusted left/right, up/down and cross angle.
7. The built-in centralized oil supply system ensures high-speed operation with low noise and no abrasion.
8. Easily recognized switches/buttons and simple operation makes it the most ideal
printing machine for adhesive labels.
Parameters
Parameters
Model Number XQ-L210C
Printing Accuracy ±0.1mm
Printing size-2 color(mm) 200*155
Printing size-3 color(mm) 200*100
Printing size-4 color(mm) 200*72.5
Max.Die-cut size(mm) 200*200
Max.paper width(mm) 210
Max paper length(mm) 300
Max.paper speed
(impression/hour) 12000
Power(V/Kw) 220/2.2
Machine size(L*M*X) mm 1950*1150*1700
Net weight(Kg) 2200
Basic configurations
1.One set of two/three/four-color printing plates, rubber rollers and iron cores respectively.
2.One piece of printing platter, upper/lower plate for die cutting respectively.
3.One number frame.
4.One paper feeding machine and paper cutting machine respectively.
5. A standard toolkit.
Optional configurations
1.Gold stamp device
2.Rewinding device
3.UV dryer
4.Computerized paper punching device.
Applicable printing materials
Self adhesive materials, tags, wash labels, Polyester and aluminum foils
This sticker printing machine is applicable to cosmetic label,Food label, water label, drug label, electronic label,bar code label etc.
