2014.11.1 New Underground Lamps 25,000lux High power miner cap lamps with 12Ah

Multiful Function and High Performance Cap Lamp!

The brightest light and best safety for yours.

Brightness is up to 25000lux ! Weight is light for portable use.

Fire-resistant, flame retardant, crash-proof, water-proof,

dust-proof, high temperature resistant ,high reliable and durable.

Widely use ! For industrial lighting and fire lighting !

15000lux 18hours working time , 25000lux strong brightness lighting for longer

lighting distance, long lifespan of 100000hours , IP68 20meters diving water-proof grade. Special

fire-resistant and steel hardness material for the lamp case, Professional for miner's safety lighting and

fireman lighting.



High capacity Li-ion battery, 6hours charging time !



12400mAh rechargeable Li-ion battery for 18hours working time to meet the long



working time underground. Charging full in 6hours .

A. Safe and Reliable: KL12LM Safe and Explosion Proof meets the relevant International Standards.The caplamp is equipped with circuit protection which prevents overchage and short circuit.The short circuit protector also has recovery function. This ensures an absolutely safe and reliable working condition for users.



B. Ergonomic Design Light Weight: KL12LM have modular assembly with tamperproof design which perfectly fits the user's helmet.Compared with the traditional Caplamp weighing 750g, KL12LM only have 490g and enhancing his comfort and efficiency.





C. Longer Working Period and Brighter Illumination: KL12LM Caplamps are capable of operating for more than 18 hours after it is fully charged and provide consistent bright illumination of more than 25,000 lux for the entire duration of use. Brighter illumination adds to better working conditions and makes the workplace safe.



D. Maintenance Free and Environment Friendly: Lithium Ion batteries provided in these lamps do not leak acid unlike conventional lead-acid batteries and the lamps require no maintenance, other than periodic charging.



E. Waterproof Design: KL12LM Caplamps have a high water and dust ingress protection confirming to IP-68 standards.

Technical Specifications KL12LM-A cord cap lamp

Light sourceone main light and two auxiliary lights

Battery capacity10.4Ah

Rated Voltage3.7V

Main light current (strong light)1000mA

Main light current (working light)600mA

Power of the main light (strong light) 3w

Power of the main light (working light) 1.8W

Illuminous(strong light) 348LUM

Illuminous(working light) 240LUM

Brightness of the main light (strong light) 25000lux

Brightness of the main light (working light) 15000lux

Life span for main LED 100000hours

Battery cycles 1200 cycles

Charging time 6 hours

Cable length 1.2m 0r 1.6m

Weight 490g

Water-proof grade IP68

Certified CE&ATEX

2014.11.1 New Underground Lamps 25,000lux High power miner cap lamps with 12Ah
