pony rod

Sucker rod

1.Grade:C,D,K,KD,HL,HY,KH

2.Size:5/8",3/4",7/8",1",1-1/8"

3.tensile strength:620-1195Mpa

3.Long lifetime,anti-corrosion

4.API 11B

Introduction

Steel sucker rod is one of the important equipment in oil field. our company can provide sucker rods including grade C, K, D, KD, HL, HY and KH. Among them, grade C, K, D sucker rods are designed and manufactured according to the API Spec 11 B, grade KD, HL and HY according to SY/T5029-2006 standard, and grade KH according to company's specification.

Grade C sucker rod is made from fine carbon steel. It is featured by mid-strength, good plasticity, toughness, corrosion resistance. It is suitable for sour medium environment where it is not susceptible to sulphuric stress cracking.

Grade D sucker rod is made from fine alloy steel, featured by high strength, better plasticity and long service life after heat treatment. This product is suitable for no-corrosion or light-corrosion environment oil-well widely.

Grade HL and HY sucker rods are super-high strength sucker rod, having the same size and main parameter as grade D sucker rod, but their strength is capable to reach 966~1195Mpa. Grade HL, HY sucker rods are suitable for the deep oil-well or big-pump capacity oil-well.

And grade K, KD and KH sucker rod are made from fine Cr-Ni-Mo alloy steel containing different amount of Ni. They possess more powerful anti-corrosion function. The products are suitable for strong corrosion oil-well, with depth of shallow, middle and deep respectively.
