High Efficiency 33KW Three Phase String Solar Power Inverter
$1385~$1500
Min.Order
1
Piece / Pieces
Model Number: SUN-33K-G
Payment Type:
Others,
Trade Terms:
CIP,
Min. Order: 1
Size: 700*575*309mm
Product Attributes
Company Profile
Logistics and other information
VR link:
Quality certification:
- Country of origin: Zhejiang,china
- Brand: Deye
- HS code:
- Yield: 20000 Piece/Pieces per Month
- Type of shipping: ocean shipping
- Port of shipment: Ningbo
- Supply capacity: 20000 Piece/Pieces per Month
- Packing method: Carton;Pallet;Wooden Case
Product Details
1. Max Efficiency of 98.7% and wide input range.
2. Multiple MPPT design with precise MPPT algorithm.
3. Natural cooling, IP65 protection.
4. Compact and light design for easy Installation.
5. Transformerless GT topology.
6. RS485, WiFi Interface.
7. Numerous protection functions.
8. Phone APP monitoring available.
9. 5 years standard warranty, 25 years lifespan design.
| Technical Specifications | |||||
| Model | SUN-25K-G SUN-30K-G SUN-33K-G SUN-45K-G SUN-50K-G | ||||
| Energy source | Grid-connected PV | ||||
| Input Side | |||||
| Max.DC Power(kW) | 27.5 | 33 | 36.3 | 49.5 | 55 |
| Max.DC Input Voltage(V) | 1000 | ||||
| Start-up DC Input Voltage(V) | 200 | ||||
| MPPT Operating Range(V) | 250~950 | ||||
| Max.DC Input Current(A) | 20+20 | 20+20 | 20+20 | 20+20+20 | 28+28+28+28 |
| Number of MPP/Number of Strings | 2/6 | 2/6 | 2/6 | 3/9 | 4/12 |
| Output Side | |||||
| Rated Output Power(kW) | 25 | 30 | 33 | 45 | 50 |
| Max. Active Power(kW) | 27.5 | 33 | 36.3 | 49.5 | 55 |
| Rated AC Grid Voltage(V) | 380/400 | ||||
| AC Grid Voltage Range(V) | 277-460 | ||||
| Rated Grid Frequency(Hz) | 50/60(Optional) | ||||
| Operating Phase | Three phase | ||||
| Rated AC Grid Output Current(A) | 36.5 | 43.5 | 48 | 65.2 | 72.4 |
| Output Power Factor | >0.99 | ||||
| Grid Current THD | <3% | ||||
| DC Injection Current(mA) | <0.5% | ||||
| Grid Frequency Range | 47-52 or 57-62(Optional) | ||||
| Efficiency | |||||
| Max. Efficiency | 98.7% | ||||
| Euro Efficiency | 98.3% | ||||
| MPPT Efficiency | >99% | ||||
| Protection | |||||
| DC Reverse-Polarity Protection | Yes | ||||
| AC Short Circuit Protection | Yes | ||||
| AC Output Overcurrent Protection | Yes | ||||
| Output Overvoltage Protection | Yes | ||||
| Insulation Resistance Protection | Yes | ||||
| Ground Fault Monitoring | Yes | ||||
| Surge Protection | Yes | ||||
| Islanding Protection | Yes | ||||
| Temperature Protection | Yes | ||||
| Integrated DC Switch | Optional | ||||
| General Data | |||||
| Size(mm) | 700W*575H*309D | ||||
| Weight(kg) | 55 | ||||
| Topology | Transformerless | ||||
| Internal Consumption | <1W(Night) | ||||
| Running Temperature | -25-60℃ | ||||
| Ingress Protection | IP65 | ||||
| Noise Emission(Typical) | <30 dB | ||||
| Cooling Concept | Natural convection | Natural convection | Natural convection | Natural convection | Forced cooling |
| Max. Operating Altitude Without Derating | 2000m | ||||
| Designed Lifetime | >20 years | ||||
| Grid Connection Standard | EN50438,IEC61727,VDE4105 NB/T32004(CQC),IEC62109-1-2 | ||||
| Operating Surroundings Humidity | 0-100% | ||||
| Stafty EMC /Standard | IEC62109-1/-2,AS3100,NB/T 32004,EN61000-6-1 | ||||
| Features | |||||
| DC Connection | MC-4 mateable | ||||
| AC Connection | IP67 rated plug | ||||
| Display | 3.5TFT | ||||
| Interface | RS485/RS232 | ||||
Deye residential monitoring solution take great care to ensure that your PV system is in excellent operation throughout its entire life-cycle.This monitoring solution offer you details information of your power generating plant including Today energy,Monthly energy,yearly energy,total energy etc,through wireless communication with your router to the internet by an smart WIFI plug.User can easily access to the monitoring page via PC web or phone APP.
