Bikaneri Bhujia Packing Machine

$15000~$25000
Min.Order 1   Set / Sets
Model Number: HP-1040a08
Payment Type: L/C, T/T, Paypal, Money,
Trade Terms: FOB, CFR, CIF,
Min. Order: 1
:
Contact Supplier

Favorite

Inquiry Basket

Product Attributes
Company Profile
Logistics and other information
VR link:
Quality certification:
  • Country of origin: Shanghai,China
  • Brand: Huihe
  • HS code:
  • Yield:
  • Type of shipping: ocean shipping
  • Port of shipment: Shanghai
  • Supply capacity: 10 Set/Sets per Week 3 sets per week
  • Packing method: Packed into 5 standard export wooden case
Product Details
Quick Details
Warranty:
1 Year
Type:
Other, Packing machine
Applicable Industries:
Hotels, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Food & Beverage Shops
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
None
Showroom Location:
None
Condition:
New
Application:
Chemical, Commodity, Food, Machinery & Hardware, MEDICAL
Packaging Type:
Bags, Film, Foil, Pouch
Packaging Material:
Plastic
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V 50Hz, 220V 50Hz
Power:
2.2 kw, 2.2kw
Place of Origin:
Shanghai, China
Brand Name:
Huihe
Weight:
650KG
Dimension(L*W*H):
(L)1217*(W)1015*(H)1343mm
Certification:
CE;ISO
Key Selling Points:
Multifunctional
Bikaneri Bhujia Packing Machine:
for a variety of packaging materials
Packing speed:
5-60bag/min
Range of measurement:
150-1500ml
Bag length:
80-300mm
Bag width:
60-200mm
Dimension:
(L)1217*(W)1015*(H)1343mm
Film thickness:
0.04-0.08mm
Supply Ability
Supply Ability
10 Set/Sets per Week 3 sets per week
Packaging & Delivery
Packaging Details
Packed into 5 standard export wooden case
Port
Shanghai

Bikaneri Bhujia Packing Machine



Feature

1.Siamesed Weigh-pack designMicrocomputer scales and packaging machine unified operation,improve the weighing and packing speed.

2.High precision, small target weighing.Choose the best combination, high accuracy and high speed combination.

3.Simple high speed operationMicrocomputer control, touch screen display, convenient operation and maintenance.

4.Contracted spaceUnique weighing packaging design, vastly reduce the height and save space.

5.Precise positioning: Servo control tension membrane, tension membrane accurate positioning,

Electric automatic tracking and trademark accurate location.

6.Quick return on investment: largely save raw material and labor cost.



Main Function

It can fully automatic process including sub-weighing, filling, film-pulling, making bags, punching, printing, and counting.



Application

Suit for the packing of the high accuracy and easy fragile granule material, such as puffed food, biscuit, rice crust, jelly, candy, pistachio nut, apple flake, dumpling, rice dumpling, chocolate, screw,bolts,hardware and medicine etc.

Bikaneri Bhujia Packing Machine





Specification of machine

Model

HP-1040a08

HP-1440a05

HP-1040b10

HP-1250a10

Display Screen

10.4 inch touch screen

10.4 inch touch screen

10.4 inch touch screen

10.4 inch touch screen

Weigh Head Nos.

10 14 10 12

Weigh Volume (liters)

0.8L 0.5L 1L 1L

Hopper material

304SS 304SS 304SS 304SS

Single Weighing Range (g)

10-500g

10-500g

10-1000g

10-1000g

Max. weight(g)

1000g 1000g 1000g 1000g

Weighing accuracy (g)

±0.3~1.5g



±0.3~1.5g



±0.5~1.5g



±0.5~1.5g

Max width of roll film(mm)

 400mm  400mm  400mm  400mm

Bag width (mm)

 60-190mm  60-190mm  60-190mm  60-240mm

Bag length (mm)

 50-230mm  50-230mm  50-230mm  50-290mm

Fill Roll

  Laminated film(OPP/CPP,OPP/PE,

MST/PE,PET/PE etc)

  Laminated film(OPP/CPP,OPP/PE,

MST/PE,PET/PE etc)

  Laminated film(OPP/CPP,OPP/PE,

MST/PE,PET/PE etc)



Laminated film(OPP/CPP,OPP/PE,

MST/PE,PET/PE etc)

Film driving mode

 Servo motor  Servo motor  Servo motor  Servo motor

Horizontal sealing driving mode

 Cylinder  Servo motor  Cylinder  Servo motor

Air consumption

  0.3³/min,0.6MPa   0.3³/min,0.6MPa   0.3³/min,0.6MPa   0.3³/min,0.6MPa

Max.Packing Speed(bags/min)

  60bag/min  100bag/min   60bag/min   100bag/min

Power

 4KW  5KW  4KW  4KW

Voltage

  220V50/60Hz(optional)   220V50/60Hz(optional)   220V50/60Hz(optional)   220V50/60Hz(optional)

N/W/G/W

  500kg/700kg   540kg/740kg   550kg/750kg   650kg/850kg

Dimension

  1556*1366*2078mm   1556*1366*2078mm   1530*1300*2300mm   1630*1320*2600mm



Packing samples

Bikaneri Bhujia Packing MachineBikaneri Bhujia Packing Machine



After Sales Service:

1.Guaranty: One Year.



2.One set of consumable accessories will be provided with the machine.



3.Any question, you can mail/call us at any time. And our most experienced engineers are assigned to give consulting service, and always available for dispatching abroad.



4.All spare parts are always available for delivery.



5.Manual is in English.



Installation/ Training

If really dont know how to install and operate after showing the video and telephone instruction, you can ask for installation from us. It must be after shipment till the machine has arrived and factory must be ready equipped with all necessary requirements before booking installation. Our engineers will come to the site for the complete and final installation. During the installation session, a one-day training course will be provided to our customers about operation and maintenance procedure. The following costs should be paid by the buyer, including engineer's all local transportation, accommodation, and air tickets (round trip).



Payment terms

Choose the machine type →  Goods delivery :(FOB,CIF,CFR,EXW)  →  Payment term :30% down payment as for ordering the machine (or 100 % payment that can save time )  →  Confirmed the machine requirement  →   Based on your requested to producing machine→   Though video chat or send machine picture or directly come to inspection in our factory →  Pay the rest of balance 70% → Arrange the  shipment .(If need more technical support ,please contact our services )
