Flexible Manufacturing Horizontal Torno Bench Matal Lathe Machine

Flexible Manufacturing Horizontal Torno Bench Matal Lathe Machine

$999~$5020

Min.Order 1 Set / Sets

Min. Order: 1

Favorite

Inquiry Basket

Product Attributes

Company Profile

Logistics and other information

VR link:

Quality certification:

Product Details

ITEMS	SPECIFICATION/ Model
ITEMS	C6241X750
Swing over bed	410mm (16")
Swing over cross slide	255mm (10")
Swing in gap diameter×width	580(22")×190 (7 1/2")
Height of center	205mm (8")
Distance between centers	750mm (40")
Width of bed	250mm (10")
Cutting tool max section	20×20mm ( 3/4 "× 3/4 ")
Total travel of cross slide	210mm (8 1/2 ")
Total travel of top slide	140mm (5 1/2 ")
Spindle bore	52mm (2")
Spindle nose	D1-6
Spindle morse taper in bore	M.T.No.6
Spindle speeds number	16
Spindle speeds range	45-1800R.P.M (16 steps)
Threads imperial pitches	2-72T.P.I(45Nos)
Threads metric pitches	0.2-14mm(39Nos)
Longitudinal feeds imperial	0.002"-0.067"/Rev(17Nos)
Longitudinal feeds metric	0.05-1.77mm/Rev(17Nos)
Cross feeds imperial	0.001"-0.0335"/Rev(17Nos)
Cross feeds metric	0.0291-1.019mm/Rev(17Nos)
Range of module pitches	0.3-3.5MP(18Nos)
Range of diametral pitches	8-44DP(21Nos)
Tailstock quill diameter	50mm(2")
Total travel of tailstock quill	120mm(4 3/4 ")
Taper in tailstock quill	M.T.No.4
Spindle drive motor	4kw
Coolant pump motor	4P,3PH 90W
9 Packing size	206(81")(256)×90(35 7/16 ")×164cm(64 9/16 ")
Net weight	1150kg
Gross weight	1350kg
