Easy Using 3.0mm Sc Single Mode Fiber Connectors Convenient MaintainingSingle Mode Fiber Optic Conne

Description

   Optical fiber connector is a device for detachable (movable) connection between optical fiber and optical fiber. It precisely connects the two end faces of the optical fiber so that the optical energy output by the transmitting fiber can be coupled to the receiving fiber to the maximum extent And to minimize the impact on the system due to its involvement in the optical link, this is the basic requirement for fiber optic connectors.

Specifications:

- Insertion Loss: Single mode ≤0.20dB & Multimode ≤0.25dB
- Return Loss: PC ≥50 dB, UPC ≥55 dB & APC ≥65 dB
- Durability <0.20 dB typical change, 1000 mating
- Operating Temperature: -40 to + 80ºC
- Ferrule Hole Sizes:
- Single mode: 125.0+1/-0μm, Concentricity: ≤1.0μm, 125.5+1/-0μm, Concentricity: ≤1.0μm, 126.0+1/-0μm, Concentricity: ≤1.0μm

- Multi mode: 125μm, Concentricity: 1≤3μm or 127μm, Concentricity: 1≤3μm or 128μm, Concentricity: 1≤3μm

Application:

• Local area networks

• Wide area networks

• Data processing Networks
