China AAAC cable All Aluminum Alloy Conductor

Type of Service Drop Cable:

Service Drop Cable covers mainly three types:

Duplex Service Drop

Triplex Service Drop

Quadruplex Service Drop

The cable can be produced whose construction is phase conductor with neutral bare conductor or phase conductor with insulated neutral conductor, etc. And we can still produce the cables according to the request of customers.

Conductors are concentrically stranded, compressed 1350-H19 aluminium. Insulated with either polyethylene or XLPE. Neutral messengers are concentrically stranded 6210 AAAC, AAC or ACSR

Quadruplex Service Drop

Applications

Used to supply 3 phase power, usually from a pole-mounted transformer to the use`s service head where connection to the service entrance cable is made. To be used at voltages of 600 volts or less phase to phase and at conductor temperature not to exceed 75 for PE insulated conductors or 90 for XLPE insulated conductors.

1. Application of Service Drop Cable:

Service Drop Cable are mainly used for electric power tranmission, rebuiding of urban and forest regions.

They can improves safety and reliance of electrified wire netting.

1. B-230 Aluminum Wire, 1350-H19 for Electrical Purposes.

2. B-231 Aluminum Conductors, Concentric-Lay-Stranded.

3. B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).

4. B-399 Concentric-Lay Stranded 6201-T81 Aluminum Alloy Conductors.

5. B498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR).

6. Duplex Service Drop cable meets or exceeds all applicable requirements of ANSI/ICEA S-76-474.
