Data Logger RT205

Description:

RT205 is an item of universal recorder, which can record procedure value of 1 channel. It has big LCD. Besides, it can be connected with software "HY data logger" via RS232. In that way it can inquire and print record on computer. It is widely applied to the procedure record in the fields of food-processing, food transportation, industrial process control and chemical and other relative fields.

Function:

① Available to many types of sensor(0-5V,0-20mA,+/-50mV,

pt100(-100-500C))without any change of hardware

② It can set procedure value and unit

③ Record capacity can reach 15000dots at a maximum;

④ 12864 LCD which can display procedure value, status, time and input sensor type

⑤ Alarm Output: Relay

Good quality

Long service time

Good after-sales service

Competitive price

Housing: 96x96x103mm ABS

Mounting Type: flush type

Mounting Hole: 90x90mm

Ambient Temperature:-20-50C

Humidity: 10-90%

Display: 128*64 dots

Power supply: 220VAC/50Hz

Input Type: 0-20mA,0-5V,+-50mv,PT100 (DIN 43670Standard,6=0.00385)

Accuracy: Gamut:0.002

Storage Capacity:15000 sample points(Max)

Functions: Display/ Record/ Alarm against higher-limit and lower limit/RS232 interface

Relay: 3A

Sensor length: Optional

refrigeration trucks, cold chain, food processing, laboratory, incubator, pharmaceutical, temperature control, and so on.
