Stage Lighting Controller/ArtNet to DMX Converter

1.General information



ETH-500 Converter is a eight universe ethernet to DMX gateway device using ArtNet protocol.

Each universe can run up to 512 DMX channel. Suitable for low to mid size matrix and Large installation requires multiple DMX universe.

It can handle network data packet of ArtNet protocol switching to standard DMX512 data. There are four standard DMX512 data output port, total can output 2048 (512 X 4) data.

It is use for LED lattice and large number of DMX512 data of stage lighting control network, such as night bar,KTV,dance hall,etc.



2.Specifications



Auto sensing universal power adaptor

LED indicator for power status

1 x Ethernet input, 4 x DMX output

5 pin XLR and RJ45 for DMX output connection



2.1 Input Voltage: DC24V/500mA

2.2 Power: 2.5W

2.3 Control and Programming

Protocols: ArtNet,DMX

DMX Channels: 2048 Channels





3. Shape Dimension and Weight

Color: Black

Anodizing black aluminum housing



Length: 118mm

Width: 104mm

Height: 28mm

Net weight: 230g

Gross weight: 700g



Packing size:18*10*12cm
