. Soda Pop/Soda Water/Filling Machine DCGF32-32-10

The series equipment is used for filling carbonated drink in bottles made of polyester or plastic.
Characteristics:

the machine can carry out the three functions of bottle washing, filling, capping.
the advanced programmed controller (PLC) is adopted to control the machine running automatically.
the bottle entry section adopts air conveyor system.
the bottle exit section adopts belt conveyor system, which can adjust the speed.
the machine are of high quality,the key spare-parts are made by famous producer


main technical specification
Model
DCGF 14-12-5 DCGF 16-12-6 DCGF 18-18-6 DCGF 24-24-8 DCGF 32-32-10
ProductionCapacity(500 ml/b/h)
2000-2500 2000-2500 3000-5000 6000-8000 8000-10000
Washing heads
14 16 18 24 32
Filling heads
12 12 18 24 32
Capping heads
5 6 6 8 10
Suited bottle PET round or square bottle
Diameter of bottle 50-90
Height of bottle 150-310
Pneumatic pressure(Mpa) 0.3-0.7
Washing medium sterile water
Washing pressure 0.25
Total power (KW) 3.13 3.13 3.84 3.84 5.6
Dimension (mm) 2250x1600x2100 2250x1640x2100 2430x1800x2100 3050x2060x2100 4050x2300x2100
Total weight ( kg) 2200 2500 3000 4000 5000
