PVC Insulated Electric Wires /house electric wire /residential building wire

PVC Insulated Electric Wires /house electric wire /residential building  wire

Standard: IEC 60227, GB/T 5023.3-2008
Rated voltage: 450/750V or 300/500V
Rated temperature: 70o C
Conductor: Solid/stranded/flexible annealed bare coppper
Insulation: PVC (Polyvinyl-chloride)
Application: This products are suitable for linking the household electrical appliance, small electric tools, instruments and power lighting devices.

Type Discription Rated      Voltage (V) Production Range
Core Quantity Cross- Sectional Area (mm2 )
227IEC01(BV) Solid copper conductor PVC insulated wire 450/750 1 1.5~400
227IEC02(RV) Flexilble copper conductor PVC insulated wire 450/750 1 1.5~240
227IEC05(BV) Solid copper conductor PVC insulated wire 300/500 1 0.5~1
227IEC06(RV) Flexilble copper conductor PVC insulated wire 300/500 1 0.5~1
227IEC07(BV-90) Solid copper conductor PVC insulated wire 300/500 1 0.5~2.5
227IEC08(RV-90) Flexilble copper conductor PVC insulated wire 300/500 1 0.5~2.5
227IEC10(BVV) Solid copper conductor PVC insulated PVC sheathed round wire 300/500 1-5 1.5~35
227IEC42(RVB) Flexible copper conductor PVC insulated  parallel wire 300/500 2 0.5~4
227IEC52(RVV) Flexilble copper conductor PVC insulated PVC sheath flexible wire 300/300 2-3 0.5~0.75
227IEC53(RVV) Flexilble copper conductor PVC insulated PVC sheath circular wire 300/500 2-5 0.75~2.5
BVN Stranded copper conductor PVC insulated nylon sheathed soft wire 450/750 1 2.5~90
BVR BYR Stranded copper conductor PVC/PE insulated soft wire 450/750 1 2.5~70
BLV Aluminum conductor PVC insulated wire 450/750 1 2.5~400
BVVB Solid copper conductor PVC insulated PVC sheath flat wire 300/500 2-3 1~6
BLVV BLVVB Aluminum conductor PVC insulated PVC sheathed circular/flat wire 300/500 2-3 2.5~6
RVVB Flexible copper conductor PVC insulated PVC sheathed soft wire 300/300 2-3 0.5~2.5
RVS Copper conductor PVC insulated PVC sheath soft twisting wire 300/300 2 0.5~1
RVVP Flexible copper conductor PVC insulated braided shield wire 300/300 1-37 0.75~2.5
