Automatic instant cup noodles shrink wrapping machine

Instant cup noodles automatic heat shrink wrapping mchine



1.Single servo motor with high control precision realizedstep-less control.



2.Large color touch screen store,pick up,automatically adjust,track,find cutting point,alarm,indicate barriers,accumulatively count packs, bag length and speed automatic display, which can realize precise cut and seal.



3.With photo-cell detecting the color mark and dual-tracing system, this machine can effectively eliminate any packing error and avoid materials waste.



4.New type vertical sealing design makes the seal at low temperature, which effectively reduces the film burning and packing wastes.



5.Adjustable bag former and pitches enable the change of packing products more conveniently.



6.With timing belt transmission, this machine has appearance, lower noise and less shake.



7.Double temperature area in shrink stove can achieve automatic temperature control.



8.Efficient air circulation ensures the quality of contraction.



9.Redundant film resection and recovery device.

instant cup noodles shrink wrapping machine

1.Servo motor,PLC control

2.Based Japan technology

3.24years experience.

Main Technical Data



FFB Parameter

FFB4512

FFB4515

FFB4518

FFB5912

FFB5915

FFB5918

FFB5921



Max film width(mm)

450

450

450

590

590

590

590



Pack speed(bag/min)

30-220

30-150

30-130

30-180

30-150

30-130

30-120



Pack size(mm)

Length

70-450

80-450

90-450

70-450

80-450

90-450

100-450



Width

10-150

10-150

10-150

10-200

10-200

10-200

10-200



Height

5-45

5-65

5-85

5-65

5-85

15-120

15-140



Electric Power Voltage(V)

220

220

220

220

220

220

220



Total power(kw)

Packaging machine

3.6

3.6

3.6

4

4

4

4



Shrink Stove

16.5

16.5

16.5

16.5

16.5

16.5

16.5



Diminsion (mm) L*W*H

Packaging machine

5700 u00d71050u00d71700

5700 u00d71050u00d71700

5700 u00d71050u00d71700

5700 u00d71250u00d71800

5700 u00d71250u00d71800

5700 u00d71250u00d71800

5700 u00d71250u00d71800



Shrink Stove

(2400-3000) u00d7600*1650



Total weight(kg)

1000

1000

1000

1000

1000

1000

1000

This heat shrink wrapping machine is used for heat shrinking,widely used in the instand food,such as instant cup/bowl noodles,cup coffee;soaps,boxes, bottles,spicy jars,and other solid articles first or secondery packages.
