1.Simple structure, easy to operate.
2.Data remote display screen and remote control device available.
3.Free installation and debugging guidance.
4.Models can be customized according to customer’s requirements (OEM service).
Technical data
Exhaust pressure (bar): 8-20
Flow rate (m³/h): 1-5, 6-15
Inlet pressure (bar): 0-6
Model | Flow rate m3/h | Inlet pressure MPa | Exhaust pressure MPa | Power KW | L×W×H mm | Connection size RC |
ZWZD-5/1.5-10 | 5 | 0.15 | 1.0 | 1.5 | 800×600×1000 | 1/2 |
VWZD-10/1.5-10 | 10 | 0.15 | 1.0 | 2.2 | 800×600×1000 | 1 |
VWZD-15/1.5-10 | 15 | 0.15 | 1.0 | 3.0 | 800×600×1000 | 1 |
WWZD-20/1.5-10 | 20 | 0.15 | 1.0 | 4.0 | 1000×650×1100 | 1 |
WWZD-25/1.5-10 | 25 | 0.15 | 1.0 | 5.5 | 1000×650×1100 | 1 |
WWZD-30/1.5-10 | 30 | 0.15 | 1.0 | 5.5 | 1000×650×1100 | 1 |
WWZD-50/1.5-10 | 50 | 0.15 | 1.0 | 7.5 | 1000×650×1100 | 1 |
ZWZD-5/4-14 | 5 | 0.4 | 1.4 | 1.5 | 800×600×1000 | 1/2 |
ZWZD-10/4-14 | 10 | 0.4 | 1.4 | 2.2 | 800×600×1000 | 1 |
ZWZD-15/4-14 | 15 | 0.4 | 1.4 | 2.2 | 800×600×1000 | 1 |
VWZD-20/4-14 | 20 | 0.4 | 1.4 | 3.0 | 800×600×1000 | 1 |
VWZD-25/4-14 | 25 | 0.4 | 1.4 | 4.0 | 800×600×1000 | 1 |
VWZD-30/4-14 | 30 | 0.4 | 1.4 | 5.5 | 800×600×1000 | 1 |
WWZD-50/4-14 | 50 | 0.4 | 1.4 | 7.5 | 1000×650×1100 | 1 |
