uhmwpe sand dredging pipe

Ultra-high molecular weight polyethylene (UHMWPE) is a kind of engineering thermoplastics with more than 3 million viscosity-average molecular weight. It differs from PE standard grades in its very high degree of polymerization. Ultra-high molecular weight polyethylene pipe has superior performance over conventional HDPE pipe such as very high wear resistance, impact resistance, intrinsically self-lubricating, anti-adhesion,low temperature resistance and excellent chemical resistance.

1.Extremely high wear resistance;

The wear resistance of uhmwpe pipe is 6.6 times higher than normal alloy steel, 27.3 times that of stainless steel, 4-7 times 17.9 times that of phenolic resin,6. 4 times that of polyethylene

2.High impact resistance: It won't damage by Cantilever beam impact test according to GB1843 standards

3.High corrosion resistance: The uhmwpe pipe can withstand hydrochloric acid with less than 80% concentration

4.High-pressuer resistance: The working pressure of uhmwpe pipe is between 0.2Mpa to 4.0Mpa

5.Good self-lubrication: The self-lubrication of uhmwpe pipe is better than steel or brass with oil

6.The unique resistance to low temperature:The uhmwpe pipe can be used within -269 to 80 degrees Celsius.

7.Not easy to form dirt: The uhmwpe pipe can't form dirt in the medium with PH value of 9 or above

8.Long life-span:The uhmwpe pipe can maintain more than 70% mechanical properties after it is buried and used for 50 years.

9.Easy installation:The weight of unit length of UHMWPE pipe is only one-eighth of the steel pipe, it is possible whether it is welded or connected by flange

Product NameUHMWPE Pipe

MaterialUHMWPE 3.5miilion molecular weight

ClourBalck, White, Yellow, or as request

SizeDN30-DN1200mm,

Length :depand on order

Thickness:8-50mm

certificationISO,CE,SGS,ROHS

Working temperature-265 degrees to 85 degrees

Working pressure0.6 Mpa-2.5Mpa

connectionSteel Flange or welding

StandardISO

Packingstandard package for sea transportation,loaded in container

characteristicRoughness:0.00022

Elongation:over350%

Coefficient of friction:0.0084

Electric power plant:Piping for transporting fly ash, dry powder, and slurry.

Shipping industry:For clearing shiping lane and transporting the silt.

Chemical industry:For transporting all kinds of severely corrosive fluids.

Metallurgical industry:Piping for transporting mortar. metallurgical waste. lead particles, aluminum powder

Food industry: For transporting wheat, flour, rice, soybean, grain etc.

Coal industry: For transporting heavy medium and coal-water slurry.

Construction industry: For transporting particle and slurry.

About us

1. Dragon is certified by ISO 9001, ISO 14001 and OHSAS 18001, CE, SGS inspection is acceptable.

2.14 years experiences in production and R&D of UHMWPE pipes, plates and rods

3.20 years of service in mining & dredging

4.10 years of experience in exporting

Equipment & technology

Dragon has 24 UHMWPE pipe production lines, the biggest UHMWPE pipe manufacturer with self-owned lab

Dragon UHMWPE pipes flanges are not welded on the pipe, it is made from the pipe itself by semi-automatic flanging machine.

Service

stable product quality , supply, the good faith management

Dragon also has stock pipe and fittings for urgent orders, also to reduce small order cost.
