Specifications:
-Voltage: 5-12V
-Phase No.: 2.4
-Rated Current: 0.46-0.8A
-Phase Resistance: 11-15ohm
-Phase Inductance: 5.2-8.6mH
-Weight: 86g
Electrical Specification | ||||||||||
Series Model | Rated Voltage (v) | No. of phase | Rated Current (A) | Phase Resistance (ohm) | Phase Inductance (mH) | Travel per Step Avail (mm) | The Mark Thrust (N) | The Mark Pull (N) | After All Journey (mm) | Motor Wgt (g) |
L351-07555-01 | 5 | 2 | 0.46 | 11 | 8.6 | 0.0254 | 55 | 55 | >=75 | 86 |
L351-07555-02 | 12 | 4 | 0.8 | 15 | 5.2 | 0.0254 | 55 | 55 | >=75 | 86 |
L351-07055 | 12 | 4 | 0.8 | 15 | 5.2 | 0.0254 | 55 | 55 | 70 | 86 |
