Product Description
BITEMAN Modular units heatless or heated regenerative desiccant air dryer
Flow rate is from 3.2-23.3m3/min,115-820 scfm,pressure dew point is -70u00baC / -94u00baF and -40u00baC / -40u00baF,-20u00baC / -4u00baF air dryers are available
Compare to Twin tower air dryers,Split the big vessel into certain number desiccant units,advantages
1.Air flow equally pass through cartridges,efficiently and accurately dry and regenerate
2.Avoid tuneling effect and uneven utilizing desiccant and regeneration
3.Replace factory filled cartridge is more easy and stable on pdp than conventional dryer
4.Is made of stainless steel and aluminum,anti-rust
PLC controller ,Full touch screen operation
1.Automatically run according to perset program
2.Low pressure alarm and automatically shut down and restart up if pressure restore
3.Pdp ,pressure digital display
4.Automaticcaly adjust purge air according to preset Pressure dew point
5.Remote control and display
Desiccant is moledular sieve ,adsorption is times of that of Alumina and silicon gel which conventional dryers use.
Product Feature
Features
- Save $3000-$20,000 a year,huge energy saving
- 1/3 size to Twin tower desiccant dryer
- Award national high-tech innovation,tens of patents in China and US
- 94u00baF(-70u00baC) pressure dew point ,-40C and -20C pdp available
- 2% purge air only,PLC control,touch screen function control
- Advanced structure,independent and replaceable,small desiccant cartirdges equally split flow
- Highly enhance the dry and regeneration
- Replace whole cartridges instead of desiccant,very easy and factory filled
- Three years desiccant working life with DITEMAN filters under proper maintenance
Product Specification / Models
Flow rate is from 1.5 to 46.5m3/min,50 to 1600 scfm,pressure dew point is -70u00baC / -94u00baF or -40u00baC / -40u00baF
and -20u00baC / -94u00baF
Application / Models
Power plant,electonics industry,food industry,madecine,home appliance factory ,and etc.
Other Information
Model NO.:BITEMAN (PDP -70Celsius -100 Fahrenheit)Operational Method:adsorption and regeneration Structure:desiccant cartridge Drier
Operation Pressure:4bar-13bar / PDP -94 F/-70c
Movement Way:Cycling between Adsorption and Regeneration Heating Mode:Heatless or heated
Air Flow:1.5-46.5m3/Min, 50-1600 Scfm
Desiccant vessel:Replaceable Cartridges, Factory Filled DesiccantPressure Dew Point:-70C,-40C,-20C
