AC/DC desktop power supply SRA-100W-12

◆ Universal Input: 100~240VAC 50~60Hz

◆ Protections: Short circuit/ Overload/ Over temperature

◆ O/P: High accuracy, low noise; hold up time≥20mS

◆ Cooling by free air convection; Auto recovery;

◆ Operation temperature: -10℃~+40℃;

◆ 100% full load burn-in test for 8 hours

◆ High Efficiency, high reliability;

◆ Built-in Class B EMI Filter

◆ Long life of 50,000Hours, 3 years warranty

◆ Compliance to EN55022 / EN60950 / IEC60950



SPECIFICATION

MODELSRA-9V-100WSRA-12V-100WSRA-24V-100WSRA-30V-100W

OUTPUTDC VOLTAGE9V12V24V30V

RATED CURRENT11A9.0A5A3.3A

CURRENT RANGE0~11A0~9.0A0~5A0~3.3A

RATED POWER100W100W100W100W

RIPPLE&NOISE(max)80mVp-p100mVp-p200mVp-p250mVp-p

LINE REGULATIONu00b1 1%u00b1 1%u00b1 1%u00b1 1%

VOLTAGE TOLERANCEu00b1 5%u00b1 5%u00b1 5%u00b1 5%

SETUP TIME800ms@110VAC; 400ms@230VAC

RISE TIME50ms@110VAC/230VAC

HOLD UP TIME20ms@230VAC

INPUTVOLTAGE RANGE90~264VAC FREQUENCY RANGE47~63Hz

POWER FACTORPF>0.68

EFFICIENCY (Typ.)82%82%83%84%

AC CURRENCY2.50A/110VAC, 1.25A/230VAC

INRUSH CURRENT (max)COLD START 60A/230VAC

LEAKAGE CURRENT(max)0.75mA / 230VAC

ENERGY CONSUMPTIONThe consumption should be less than 1.0 Watt at normal input

INPUT PLUG TYPEIEC-C6 / IEC-C14

ENVIROMENTWORKING TEMP.-10℃~+40℃

WORKING HUMIDITY20%~90% RH non-condensing

STORAGE TEMP. HUMIDITY-25℃~+80℃, 10%~95%RH

TEMP. COEFFICIENTu00b1 0.05% / ℃ (0~50℃)

VIBRATION10~500Hz, 2G 10min./1cycle, period for 60min. each along X,Y,Z axes.

OTHERSDIMENSION (mm)160*55*38mm (L*W*H)
