Items | Standard | Comments |
Nominal voltage | 12.8V | |
Typical capacity | 60±3Ah | At 0.2C discharge rate |
Max continuous discharge current | 50A | |
Discharge cut-off voltage | About 10V | |
Charge input voltage | 16.4±0.2V | Charge mode: CC/CV,Use a constant current, constant voltage(CC/CV) please use special Lithium-ion charger. |
Charge current | ≤30A | |
Inner resistance | ≤60mΩ | Between positive and negative polar |
Operation temperature range | Charge | 0u2103~+45u2103 |
Discharge | -20u2103~+60u2103 | |
When the environment temperature is higher than 45u2103,please pay attention to ventilation and heat rejection. | ||
Storage temperature range | 0u2103~40u2103 (Capacity 80%) | Recommended long-term storage temperature is 15~25u2103 |
Humidity | 5%≤RH≤85% | |
Total Weight | Approx 13±1 kg | |
Size(L*W*H) | 270*170*230mm | |
Protection function | Over charge protection,Over discharge protection,Over current protection,Temperature protection ,Short circuit protection | |
Cycle Life | 1) standard charge at 0.2C(A), 5) Capacity retention rate≥80% 5000 cycles 80%DOD |
